Push-To-Open "F" Wind Lift System Kit

SKU: FRAKFEPFSN9
Description

The Wind lift system is characterized by compactness and elegant design. Its movement is smooth and perfectly controlled. Wind is small and unobtrusive, enabling the maximum utilization of cabinet internal space.

• (1) "F" Wind Kit (2 Wind - Left & Right Bracket)
• Min. door height 12-9/16"
• Max. door height 24"
• 1.4kg to 14.6kg (3.1lbs to 32.2lbs) Include the weight of the decorative hardware - SEE DOWNLOADS & LINKS FOR MORE INFORMATION
• Premounted reduction clip included on bracket arm which reduces opening to 85° and is removable for opening degree up to 110°
• Push-To-Open

COVER CAPS SOLD SEPARATELY

For Accessories: CLICK HERE • Magnetic Release Device, Magnetic Holding Device, Magnetic Retaining Catch

View related products
Main Product Features
Suggested Retail Price: $ 207.12

Please Login to view your pricing

push-to-open-f-wind-lift-system-kit-2224.pdfpush-to-open-f-wind-lift-system-kit-2224-176918.pdf

Read more about our delivery and return policy in FAQ section


Additional Details

Application Type
Flap Door
Door Height Range
12-9/16" to 24" (320mm to 610mm)
Door Weight
1.4kg to 14.6kg (3.1lbs to 32.2lbs) Include The Weight of The Decorative Hardware
Mounting Type
Side Mount
Opening / Closing Type
Push-To-Open
Opening Degree
85° to 110°
